Lintlha tsa ho rala libaka tse kobehang tsa boto ea potoloho e thata ea flex

Ha u rala libaka tse feto-fetohang bakeng sa liboto tsa potoloho tse thata, baenjiniere le baqapi ba tlameha ho nahana ka lintlha tse 'maloa tsa bohlokoa.Lintlha tsena li bohlokoa ho netefatsa hore boto e tšepahala, e ts'epahala, 'me e sebetsa lits'ebetsong tse hlokang ho tenyetseha.Ka poso ena ea blog, re tla ikakhela ka setotsoana litabeng tsena ebe re buisana ka bohlokoa ba e 'ngoe le e 'ngoe.

1. Khetho ea lintho tse bonahalang:

Khetho ea thepa ea boto ea potoloho e thata-flex e bohlokoa ho khetholla bokhoni ba eona ba ho koba.Lisebelisoa tse sebelisoang li tlameha ho ba le ho feto-fetoha ho hlokahalang le ho tšoarella ho mamella ho khumama khafetsa ntle le ho ama botšepehi ba potoloho.Lisebelisoa tse tloaelehileng bakeng sa likarolo tse feto-fetohang li kenyelletsa polyimide (PI) le polyester (PET), ha lihlopha tse thata li atisa ho etsoa ka FR4 kapa lisebelisoa tse ling tsa boto ea potoloho.Ho bohlokoa ho khetha thepa e ka mamellang radius e kobehang e hlokahalang le palo e lebelletsoeng ea lipotoloho tse kobehang.

2. Radise e kobehang:

Bend radius ke radius e nyane ka ho fetesisa eo boto ea potoloho e thata e ka kobehang ntle le ho baka tšenyo ea likarolo, mesaletsa ea conductive kapa boto ka boeona.Ho bohlokoa ho tseba sebaka se loketseng sa ho kobeha bakeng sa ts'ebeliso e itseng le ho netefatsa hore thepa e khethiloeng e ka fihlela tlhokahalo ena.Ha ho khethoa radius e loketseng ea ho kobeha, baqapi ba tlameha ho nahana ka boholo le sebopeho sa karolo, sebaka pakeng tsa mesaletsa ea conductive, le botenya ba lesela la flex.

3. Traceroute:

Ho tsamaisa litselana tsa conductive sebakeng se kobehang ke ntlha e 'ngoe ea bohlokoa.Mesaletsa e tlameha ho etsoa ka tsela e lumellang hore e kobehe ntle le ho robeha kapa ho ba le khatello e sa hlokahaleng.Ho finyella sena, baqapi ba atisa ho sebelisa litsela tse kobehileng ho e-na le likhutlo tse bohale hobane mesaletsa e kobehileng e hanyetsana le khatello ea maikutlo.Ho phaella moo, litsela tse sebakeng se kobehileng li lokela ho behoa hole le axis e sa jeleng paate ho qoba ho otlolla ho feteletseng kapa khatello nakong ea ho khumama.

4. Ho beha likarolo:

Ho beha likarolo hantle ho bohlokoa ho netefatsa ho ts'epahala le ts'ebetso ea liboto tsa potoloho tse thata-flex.Likarolo li lokela ho behoa ka mokhoa o hlophisitsoeng ho fokotsa khatello ea kelello holim'a boto nakong ea ho koba.Ho bohlokoa ho nahana ka likarolo tsa tšusumetso joalo ka lihokelo tse nang le phetoho e akaretsang ea boto.Ho beha likarolo tse ngata kapa tse thata haufi haholo le sebaka se kobehang ho ka fokotsa bokhoni ba boto ba ho koba hantle kapa ho eketsa kotsi ea tšenyo ea karolo.

5. Lekanale la litsela:

Liteishene tse hlophisitsoeng hantle tse tsamaisang li ka thusa ho thusa ho kobeha le ho kobeha ha liboto tsa potoloho tse thata.Likanale tsena ke likheo lera le thata le lumellang lera le tenyetsehang hore le tsamaee ka bolokolohi nakong ea ho kobeha.Ka ho fana ka liteishene tsena, baenjiniere ba ka fokotsa khatello ea maikutlo ho flex layer le ho qoba khatello e sa hlokahaleng ea mesaletsa.Bophara le botebo ba likanale tsa litsela li lokela ho ntlafatsoa ka hloko ho etsa bonnete ba hore li tsamaellana le radius e hlokahalang ea ho kobeha.

6. Teko le ketsiso:

Pele o phethela moralo oa boto ea potoloho e thata, ho bohlokoa ho etsa tlhahlobo e phethahetseng le papiso ho netefatsa ts'ebetso ea eona tlas'a maemo a kobehang.Ho sebelisa mekhoa ea tlhahlobo ea 'nete kapa ea' mele ho ka thusa ho tseba mathata a ka bang teng joalo ka mesaletsa ea khatello e feteletseng, manonyeletso a fokolang a solder, kapa likarolo tse sa nepahalang.Lisebelisoa le mahlale a ketsiso a bohlokoa haholo bakeng sa ho ntlafatsa meralo le ho netefatsa ts'ebetso e nepahetseng ea liboto tsa potoloho.

Ka kakaretso

Ho rala sebaka se feto-fetohang sa boto ea potoloho e thata ho hloka ho shebisisa lintlha tse 'maloa tsa bohlokoa.Khetho ea thepa, sebaka se kobehang, ho latela tsela, ho beoa ha likarolo, liteishene tsa litsela, le liteko kaofela ke lintlha tsa bohlokoa tse lokelang ho rarolloa ho netefatsa ts'epo le ts'ebetso ea boto.Ka ho ela hloko lintlha tsena, baenjiniere le baqapi ba ka etsa liboto tsa potoloho tse thata-flex tse fihlelang litlhoko tsa lisebelisoa tse feto-fetohang ha li ntse li boloka botšepehi le ts'ebetso ea tsona.
